Gaggenau Vario 200 Series 6" Black Downdraft Ventilation

Product Overview

Can be combined with the cooktops of the Vario 200 series to a harmonic unity

Highly efficient ventilation system at the cooktop integrated in the countertop

Function for automatic, sensorcontrolled power adjustment depending on the build-up of cooking vapors

Minimal planning and easy installation

Low-noise system with recirculation blower AR410 710

Air recirculation system

Output

Power levels depend on the remote blower.

Features

Control knobs with illuminated ring.

3 electronically controlled power levels and 1 intensive mode.

Automatic function with sensor-controlled run-on function.

Large-scale metal grease filter with high grease absorption.

Grease filter, dishwasher-safe.

Grease filter and activated charcoal filter saturation indicator.

Airflow-optimized interior for efficient air circulation.

Interval ventilation, 6min.

Enameled ventilation grill, dishwashersafe.

Air exhaust bend included in delivery.

Overflow 8.5 oz. (250ml) capacity.

Consumption data

Consumption data is referred to a configuration with the recirculation blower AR410 710.

Sound level min. 56 dB / max. 76 dB.

Planning notes

Air recirculation mode in combination with recirculation blower with AR410 710 or AR413 722.

For each VL one blower unit is recommended.

Maximum cooktop width between 2 VL downdraft units: 24" (60 cm).

If installed next to gas appliances, the air deflector LS041 001 is recommended to ensure maximum performance of the cooktop.

When having installed the air deflector LS041 001 the wok pan WP400 001 can not be used.

Rating

120 V / 60 Hz

Connecting cable 66" (1.7m) between VL and recirculation/inline blower.
